Project Description

About this Project

Features the following:

  • Custom-built drawknob console of Cherry
  • Peterson keyboards Maple naturals
  • Rosewood Accidentals
  • AGO standard pedalboard of Cherry Maple naturals
  • Rosewood Accidentals
  • Adjustable Organist’s Bench of Cherry to match console
  • Crank mechanism for height adjustment
  • Balanced Great/Pedal Expression Pedal
  • Balanced Choir Expression Pedal
  • Balanced Swell Expression Pedal
  • Balanced Crescendo Pedal 2 Programmable Crescendos per memory bank
  • Lighted Bar Graph for Expression positions
  • Status screen showing: Transposer position
  • Current Memory Bank
  • Current Memory Level
  • Current Crescendo
  • Transposer
  • Tremolo Full
  • Melody Coupler
  • Bass Coupler
  • Zimbelstern – w/ Reversible Thumb/Toe Pistons
  • Lighted Music Desk w/ Variable settings
  • Key Switch
  • Complete Audio System as appropriate 20 channels
  • 2 Sub-woofers
  • 2 cabinets per channel (16 channels)
  • 2 multi-directional heavy duty F. Tr. cabinets
  • Complete MIDI Implementation: 8 Programmable MIDI Drawknobs
  • MIDI In/Out/Thru Ports
  • Sequencer In/Out Ports
  • MIDI Sustain – Toe Piston
  • Auxiliary Stereo Audio Input Ports
  • Velocity key control on all manuals
  • Yamaha sequencer w/ drawer

Stop List

GREAT
Manual II
Expressive
Violone
Principal
Violone
Hohlflute
Gedackt
Octave
Spitzflute
Twelfth
Superoctave
Sesquialter II
Mixture IV
Contra Trumpet
Trumpet
Chimes
Tremolo
Festival Trumpet
16′
8′
8′
8′
8′
4′
4′
2 2/3′
2′
1 1/3′
16′
8′

8′ (Non-coupling) SWELL
Manual III
Expressive
Bourdon
Geigen Principal
Rohrflute
Viola
Viola Celeste
Flute Celeste II
Principal
Harmonic Flute
Nazard
Waldflute
Tierce
Plein Jeu IV
Basson
Trompette
Hautbois
Vox Humana
Clarion
Tremolo
Swell to Swell
Swell Unison Off
Swell to Swell
16′
8′
8′
8′
8′
8′
4′
4′
2 2/3′
2′
1 3/5′
2′
16′
8′
8′
8′
4′
16′

4′ CHOIR
Manual I
Expressive
Gemshorn
Holzgedackt
Gemshorn
Gemshorn Celeste
Prestant
Koppelflute
Principal
Quint
Sifflet
Cymbal III
English Horn
Cromorne
Harp
Tremolo
Festival Trumpet
Choir to Choir
Choir Unison Off
Choir to Choir
16′
8′
8′
8′
4′
4′
2′
1 1/3′
1′
1′
8′
8′
8′ (Non-coupling)
16′

4′ PEDAL
UnenclosedContra Violone
Prestant
Subbass
Violone
Bourdon
Octave
Rohrgedackt
Gemshorn
Choralbass
Spitzflute
Rauschpfeife II
Contra Bombarde
Posaune
Basson
Trumpet
Rohrschalmei
Chimes
Festival Trumpet
32′
16′
16′
16′
16′
8′
8′
8′
4′
4′
32′
16′
16′
8′
4′

8′ (Non-coupling) COUPLERSGreat to Pedal
Swell to Pedal
Swell to Pedal
Choir to Pedal
Choir to Pedal
Swell to Great
Swell to Great
Choir to Great
Choir to Great

Swell to Choir
Swell to Choir

Great/Choir Invert
All Swells to Swell8′
8′
4′
8′
8′
8′
4′
8′
4′

8′
4′
