Project Description

About this Project

This organ features:

  • Three-manual and Pedal Console
  • Built to American Guild of Organists standards
  • Cabinetry to match architectural woodwork in church of quarter-sawn white oak – finished to sample
  • Long-stick / wood-core keyboards w/bone naturals
  • Premium AGO pedalboard with Rosewood sharps and Maple naturals
  • Harris drawknobs for stop controls
  • Harris tilting tablets for coupler controls
  • Harris toe pistons
  • Balanced Swell expression shoe
  • Balanced Solo expression shoe
  • Balanced Crescendo shoe
  • Programmable Tutti for every memory bank
  • Programmable Crescendo I for every memory bank
  • Programmable Orchestral Crescendo for every memory bank
  • Adjustable organist’s bench
  • Key-switch for blower
  • Pedal lights
  • Lighted Music Desk
  • Transposer -6/+6
  • Complete MIDI Implementation:
    • 8 Programmable MIDI Stops as lighted thumb pistons (pinboard prepared in console)
    • MIDI In/Out/Thru ports
    • Sequencer In/Out ports
    • Auxiliary stereo audio input ports – 1/4″ jacks
  • Casework for facades:
    • Of quarter-sawn white – finished to sample
    • West wall w/Trompeta 8′ horizontal reed under window as per design drawings
    • East wall as per design drawings
    • Choir wall as per design drawings

Stop List

GREAT
Manual II Unenclosed		 Gemshorn
Principal
Bourdon
Flute Harmonique
Gemshorn
Octave
Koppelflute
Nasat
Superoctave
Waldflute
Terz
Mixture III-IV
Double Trumpet
Trumpet
Tremulant
Chimes		 16′
8′
8′
8′
8′
4′
4′
2 2/3′
2′
2′
1 3/5′
1 1/3′
16′
8′
SWELL
Manual III Expressive		 Lieblich Gedeckt
Geigen Diapason
Rohrflute
Viole de Gambe
Viole Celeste
Prestant
Nachthorn
Nazard
Principal
Blockflute
Tierce
Larigot
Plein Jeu III
Basson
Trompette
Hautbois
Voix Humaine
Clairon
Zimbelstern
Tremulant
Swell to Swell
Swell Unison Off
Swell to Swell		 16′
8′
8′
8′
8′
4′
4′
2 2/3′
2′
2′
1 3/5′
1 1/3′
2′
16′
8′
8′
8′
4′16’4′
SOLO
Manual I Expressive		 Concert Flute
Viola Pomposa
Viola Celeste
Flute Deuce Celeste II
Flute Octaviante
Piccolo Harmonique
Corno di Bassetto
Trompeta
Cromorne
French Horn
English Horn
Trompeta
Tremulant
Solo to Solo
Solo Unison Off
Solo to Solo		 8′
8′
8′
8′
4′
2′
16′
8′
8′
8′
8′
4′16’4′
PEDAL
Unenclosed		 Contra Violone
Prestantbass
Bourdon
Lieblich Gedeckt
Gemshorn
Octave
Flute
Cello
Gemshorn
Choralbass
Flute
Mixture III
Contra Bombarde
Bombarde
Basson
Trompette
Clairon
Chimes		 32′
16′
16′
16′
16′
8′
8′
8′
8′
4′
4′
2 2/3′
32′
16′
16′
8′
4′
COUPLERS Great to Pedal
Great to Pedal
Swell to Pedal
Swell to Pedal
Solo to Pedal
Solo to Pedal
Swell to Great
Swell to Great
Swell to Great
Solo to Great
Solo to Great
Solo to Great
Great to Swell
Solo to Swell
Status Screen
Swell to Solo
Swell to Solo
Swell to Solo
Great to Solo
Tuba on Great
Tuba on Great
Tuba on Great
Tuba on Swell
Tuba on Solo
Tuba on Pedal
Tuba on Pedal
Tuba on Pedal		 8′
4′
8′
4′
8′
4′
16′
8′
4′
16′
8′
4′
8′
8′16′
8′
4′
8′
16′
8′
4′
8′
8′
16′
8′
4′
