Project Description

About this Project

This organ features:

  • Custom designed and built console to match existing furniture as closely as possible
  • Drawknobs for stop controls (Harris)
  • 2 manual keyboards
  • Ivory naturals with Ebony sharps
  • 32 note pedalboard
  • Maple naturals with ebony sharps
  • Tutti – programmable for each memory bank
  • Lighted piston – reversible
  • Crescendo – programmable for each memory bank
  • Orchestral Crescendo – programmable for each memory bank
  • Lighted piston – reversible
  • Expression shoes by Harris
  • Balanced Swell Expression Shoe
  • Balanced Crescendo Pedal
  • Indicator lights for all shoes
  • New solid state switching, console control, combination action
  • Built-in castors for mobility of console
  • Adjustable lighted music desk
  • Pedalboard lighting
  • Switch for organ/blower with indicator light
  • Transposer +6/-6
  • Adjustable organist’s bench designed and finished to match console
  • Complete MIDI Implementation:
  • 2 Programmable MIDI stops per manual (and pedalboard) as lighted thumb pistons
  • MIDI In/Out/Thru ports
  • Sequencer In/Out ports
  • Auxiliary stereo audio input ports – 1/4″ jacks
  • Yamaha MDF-3 sequencer (playback) mounted in drawer under key desk
  • Storage drawer under Great manual

Stop List

GREAT
Unenclosed Manual 1
Violone
Principal
Bourdon
Dulciana
Celeste tc
Octave
Stopped Flute
Hohlflute
Mixture IV
Festival Trumpet
Trumpet
Swell to Great
16′
8′
8′
8′
8′
4′
4′
2′
1 1/3′
8′
8′
8′
SWELL
Expressive Manual II
Lieblich Gedackt
Chimney Flute
Viola Da Gamba
Voix Celeste
Principal
Harmonic Flute
Nazard
Spitz Principal
Tierce
Nasat
Festival Trumpet
Hautbois
Tremulant
Chimes
Harp
Swell Unison Off
16′
8′
8′
8′
4′
4′
2 2/3′
2′
1 3/5′
1 1/3′
8′
8′

PEDAL
UnenclosedContra Violone
Violone
Bourdon
Lieblich Gedackt
Octave
Gedackt
Choralbass
Nachthorn
Posaune
Festival Trumpet
Trumpet
Hautbois
Great to Pedal
Swell to Pedal
32′
16′
16′
16′
8′
8′
4′
4′
16′
8′
8′
4′
8′
8′
 REVERSIBLESAs Thumb Pistons Duplicated by Toe Pistons:
Great to Pedal
Swell to Pedal
Zimbelstern
Tutti – programmable for each Memory Bank

As Toe Pistons Only:
Contra Violone

As Thumb Pistons Only:
Swell to Great
Orchestral Crescendo (lighted)
Tremulants Full (lighted)
MIDI on Great (x2) (lighted)
MIDI on Swell (x2) (lighted)
MIDI on Pedal (x2) (lighted)

8′
8′

32′

8′
